Intelligent type fence perimeter detection laser sensor barrier security XL-B200C



    XL-B**C three-beam laser intrusion detector is the upgrade of XL-B double-beam product.It has more  stable core  components, more reasonable structure and increased alert density. It adopts adjacent double beams to simultaneously realize blocking alarm, with higher stability, thus dramatically increasing accuracy of alarm.



      XL-B**C series three-beam laser intrusion detector has strong ability to resist cold and heat,

electromagnetic radiation, interference of miscellaneous lights and could adapt to rough weather of wind, rain, dust, frost,

etc., thus being suitable for perimeter areas with higher alert rate requirements.

Item

Technical indexes

Model

XL-B 50/100/200/300/500 C

Laser wave length

650nm, 808nm, 980nm

Alert distance

0- 500m

Alert level

three-layer alert,layer spacing:14.5cm

Alarm mode

Beam blocking alarm

Working voltage

DC10-30Vor AC220V

Working current:

Transmitting:90mA ,receiving:120mA,80mA when receiving alarm

Alarm output mode

A set of relay normally open/normally closed contact. Contact capacity: AC125V/0.5A,DC24V/2A

Anti-dismantling output pattern

A set of normal close contact. Contact capacity: AC125V/0.5A,DC24V/2A

Angles at the transmitting and receiving ends

Divergence angle:<3′  Receiving angle: >10°

Optical axis adjustment angle

Horizontal 30°   Vertical ±30° (range adjustable.)

Product dimension

140mm (L) × 140mm (W) × 511mm (H)

Chassis dimension

140mm (L) × 140mm (W) × 10mm (H)

Material

Shell:Aluminum alloy ;Top cover, Base: ABS PC

Product weight

3.3KG (transmitting end: 1.8KG, receiving end: 1.5KG)

Dimension of installation hole

Four 20*10 holes in even distribution

Alarm time

2s±1s (1-30s optional)

Response time

5ms-500ms (adjustable)

Working environment temperature

-40℃-70℃

Protection level

IP67

Type of laser light source

Type I safety laser light source, in Class I

MTBF

> 120,000h




1,
 The oil depot, Oilfield, Oil and gas pipeline border intrusion prevention

2. Railway track obstruction warning precautions

3. Rail transit, airport runway border protection warning

4, Various important areas of  temporary cordon

5, Highway bridge over-high warning, Road and rail tunnels over-high and  Closed alarm protection
6,The military restricted zones, border intrusion alarm
